1. The core part of the equipment adopts high-precision electromagnetic balancing weighing sensor, DSP high-speed signal processing system and military aviation level software algorithm. The measurement data is accurate and rapid, the operation is stable, and the ability to resist environmental interference is very strong;
2. Can detect 000#, 00#, 0#, 1#, 2#, 3#, 4#, 5#, SA, SB and all types of capsules, as well as regular tablets;
3. The working mode of "unit extension structure" and "infinite parallel" of the whole machine makes it possible for a PC to control 1024 single machines at most at the same time, so that the working efficiency can be improved infinitely and the selection of models according to the working efficiency becomes extremely simple;
4. The mold adopts the building block bond and positioning structure. When changing the model of the capsule, the mold can be quickly disassembled and installed by hand with accurate positioning;
5. The molds of adjacent capsule models are common, such as 00# and 0# are common, 1# and 2# are common, 3# and 4# are common, to reduce the number of molds and reduce the cost of equipment;
6. Small volume, does not take up space, easy to move;
7. Reasonable design, few equipment failure points, easy to use, simple operation and maintenance, low maintenance cost;
8. Flexible work, can be used with production equipment, or can be used offline;
9. Production recipe management call, rich data statistics, data storage, query and print functions;
10. Preset qualified range, quick and automatic sorting good and bad products;
11. Ergonomic design, large size and color touch screen, humanization operation interface, intuitive chart display;
12. The human-machine interface synchronously displays the weight value of each channel, and visually displays the qualified or not of the current channel products in the form of green and red histogram respectively. The equipment synchronously lights up the indicator light, making the detection process more intuitive;
13. The innovative three-channel design of good, bad and uninspected products, which perfectly solves the discharge problem of uninspected products during abnormal shutdown and eliminates misjudgment;
14. Automatic alarm of equipment failure, prompt alarm information;
15. Comply with 21CFR Part11, three level password, electronic record electronic signature, ensure data integrity, easy for audit tracking;
16. Rich peripheral interface, Ethernet, USB, COM port, wireless Wifi, convenient for remote monitoring and networking data exchange.



Model	Efficiency	Application Capsule Size	Weighing Range	Scale Interval	Dynamic Accuracy	Power Supply; Air Supply	Dimensions; Weight
H-CMC±0.3	N*400pcs/min	000#~5#	20~2000mg	0.1mg	±0.3mg	220V ;50Hz 6~8bar	500x450x1480mm 95kg
H-CMC±0.5	N*500pcs/min	000#~5#	20~2000mg	0.1mg	±0.5mg
